Connector Type: Optical Cable Type: Fiber Optic Color: Default Brand: HTD / OEM Specification Met: ISO 9001
1*2 SC APC PLC Splitter
The loss is insensitive to light wavelength and can meet the transmission needs of different wavelength.
The signal can be distributed uniformly to the user.
Compact structure, small volume, can be directly installed in the existing various junction box, do not need to leave a large installation space.
The single device has many branch channels, which can reach more than 32 channels.
Multi-way cost is low, the more roads, the more obvious cost advantage.
Product Feature
◆ Easy Plug and Pull
◆ Low Insertion Loss
◆ Large Working Temperature Range
Product Parameter
Parameter | Unit | Data |
| Size | inch | 86.61 x 0.39 x 0.39 |
| Weight | ounce | 1.62 |
Insertion Loss | dB | ≤ 4.0 |
Loss Uniformity | dB | ≤ 0.4 |
Polarization Dependent Loss | dB | ≤ 0.2 |
Wavelength Dependent Loss | dB | ≤ 0.3 |
Return Loss | dB | ≥ 60 |
| Directivity | dB | ≥ 55 |
Storage Temperature | °C | -40 ~ +85 |
